WENZHOU JINGHUA MACHINERY CO.,LTD
 |
| Quantity: | |
|---|---|
FW550/900
BDTECH
1SET
45 days
Main characteristics:
1,The design of this machine is from Corea and has got improved; it can reach the high
quality request of slitting and rewinding fax paper, cash paper, and cardiogram printing paper, computer printing paper, taxi ticket, and commercial bill and so on.
2,It is applicable to slit the narrow scope paper, automatic counting the length (meter), setting the length, automatic stopping, also auto frequency conversion.
3,Automatic feeding and correct errors for unwinding, automatic blowing rim charge conveying device.
4,General control screen is unattached and conveniently operating
| Type | FW-550 | FW-900 |
Max width of material | 550mm | 900mm |
Max diameter of unwinding | 1000mm | 1000mm |
Max diameter of rewinding | 200mm | 200mm |
Slitting scope | 30-550mm | 30-900mm |
Paper core side | 0.5-3Inch | 0.5-3Inch |
Slitting speed | 150m/min | 150m/min |
Slitting precision | ±0.3mm | ±0.3mm |
Power | 2.2kw | 3kw |
Weight | 1700kg | 2000kg |
Overall dimensions | 1880×1570×1280(mm) | 1920×1880×1280(mm) |
Warranty : 1 year
1.Installation Services
all of our machine are available of Installation Services. if you need,We can send our engnieer to your factory to help you install your purchased machines from our factory.buyer need to pay for the round trip tickets, food,hotel and pay 80usd/day/person as sallary to our engnieer.
2.Clients Traning Services
it is a big printing machine,We can let our engnieer teach and train your operator hand by hand when our engnieer install the machines in your factory. but that time is not long,maxmum 6 days.if you need experience operator from china. you can let us kown.we can supply the experience operator to you,sallary you and operator discuss face to face.
3.After Sales Service
Our machine guarantee time is one year.
We will send many easy broken spare parts in the tool box together with machines.
If any parts broken ,please take a pictures or a videos to us.
We will help you to change it.
Main characteristics:
1,The design of this machine is from Corea and has got improved; it can reach the high
quality request of slitting and rewinding fax paper, cash paper, and cardiogram printing paper, computer printing paper, taxi ticket, and commercial bill and so on.
2,It is applicable to slit the narrow scope paper, automatic counting the length (meter), setting the length, automatic stopping, also auto frequency conversion.
3,Automatic feeding and correct errors for unwinding, automatic blowing rim charge conveying device.
4,General control screen is unattached and conveniently operating
| Type | FW-550 | FW-900 |
Max width of material | 550mm | 900mm |
Max diameter of unwinding | 1000mm | 1000mm |
Max diameter of rewinding | 200mm | 200mm |
Slitting scope | 30-550mm | 30-900mm |
Paper core side | 0.5-3Inch | 0.5-3Inch |
Slitting speed | 150m/min | 150m/min |
Slitting precision | ±0.3mm | ±0.3mm |
Power | 2.2kw | 3kw |
Weight | 1700kg | 2000kg |
Overall dimensions | 1880×1570×1280(mm) | 1920×1880×1280(mm) |
Warranty : 1 year
1.Installation Services
all of our machine are available of Installation Services. if you need,We can send our engnieer to your factory to help you install your purchased machines from our factory.buyer need to pay for the round trip tickets, food,hotel and pay 80usd/day/person as sallary to our engnieer.
2.Clients Traning Services
it is a big printing machine,We can let our engnieer teach and train your operator hand by hand when our engnieer install the machines in your factory. but that time is not long,maxmum 6 days.if you need experience operator from china. you can let us kown.we can supply the experience operator to you,sallary you and operator discuss face to face.
3.After Sales Service
Our machine guarantee time is one year.
We will send many easy broken spare parts in the tool box together with machines.
If any parts broken ,please take a pictures or a videos to us.
We will help you to change it.
