Inspecting and Rewinding Machine

loading

Share to:
sharethis sharing button
Availability:
Quantity:
  • SLR1200

  • BDTECH

  • 1SET

  • 45 days

Main characterisetics:

1,seat and wall use cost iron,iron board structure,machine is beautiful and very steady.
2,machine use PLC center control,use touch screen MCGS man-machine interface to operate.
System have defect memory,return,count meter and preset meter function.
3,unwinding tension use 4kw Taiwan vector frequency inverter control,
LPC system auto count,achieve unwinding tension automatic control.also can achieve positive/negative rewinding.
4,main machine driver is controlled by 2.2kw Taiwan motor vector frequency inverter control,
Achieve line speed control
5,use airshaft for rewinding,tension use 4KW vector frequency inverter control,use PLC auto count the diameter of rewinding,achieve rewinding tension auto control.
6,rectify use LPC photocell auto rectify system,auto track side and line,ensure material position right.
7,inspection use frequency strobe automatic track pattern.auto sychronors strobe,achieve static picture to inspect.(frequency strobe: QLY04  light is from Germeny)


material thickness 0.012-0.50mm
width of material 1200mm
diameter of unwinding 1000mm
diameter of rewinding 800mm
machinery speed 15-250m/min



6.total power: 11KwQQ截图20161215131148


Warranty : 1 year

 1.Installation Services

 all of our machine are available of Installation Services. if you need,We can send our engnieer to your factory to help you install your purchased machines from our factory.buyer need to pay for the round trip tickets, food,hotel and pay 80usd/day/person as sallary to our engnieer.



2.Clients Traning Services

 it is a big printing machine,We can let our engnieer teach and train your operator hand by hand when our engnieer install the machines in your factory. but that time is not long,maxmum 6 days.if you need experience operator from china. you can let us kown.we can supply the experience operator to you,sallary you and operator discuss face to face.



3.After Sales Service

 Our machine guarantee time is one year.

 We will send many easy broken spare parts in the tool box together with machines.

 If any parts broken ,please take a pictures or a videos to us.

 We will help you to change it.
